Engine

Make:   SINOTRUK

Engine   model: WD615.62, Euro II emission standard

4   stroke direct injection diesel engine

6   cylinder in-line with water cooling, turbo-charging & intercooling

Maximum   output: 266hp(196Kw) at 2200 rpm according to DIN

Maximum   torque: 1100Nm at 1100~1600 rpm

Bore:   126mm;   Stroke: 130mm;

Displacement:   9.726L;  Compression ratio: 17：1

Specific   fuel consumption: 195g/kWh;  Engine oil   filling quantity: 23L

Cooling   system filling quantity (long-term filling): 40L

Thermostat   opening temperature: 71^oC

Twin   cylinder air compressor      Rigid fan

Clutch

Single-   plate dry coil-spring clutch, diameter 420mm, hydraulically operating with   air assistance

Transmission

Transmission,   model HW15710,10 forward and 2 reverse,Fuller technology of main housing and   quality standard, without synchromesh

Ratio:   14.28 10.62 7.87 5.88 4.38 3.72 2.43 1.80 1.34 1.00 13.91/3.18(R)

Propeller   Shaft

Double   universal joint propeller shaft with gear-shaped coupling flange

Front   Axle

H153  Rated Loading capacity:5500KG Steering with   double T-cross section

Rear   Axles

ST16    Rated Loading capacity:16000KG

Pressed axle housing, central single reduction and   differential locks between axles

Ratio:   5.73

Chassis

Frame:   U-profile parallel ladder type with section of 300×(8+4)mm, all cold riveted cross members and reinforced   subframe

Front   suspension: 9 leaf springs with hydraulic telescopic double-action shock   absorbers and stabilizer

Rear   suspension: 9+6 semi-elliptic leaf springs with bogie spring and stabilizer

Spare   wheel carrier: with one spare wheel

Fuel   tank: with one 400 L fuel tank with locking fuel cap

Steering

Hydraulic   steering with power assistance

Brakes

Service   brake: dual circuit compressed air brake

Parking   Brake: spring energy, compressed air operating on rear wheels

Auxiliary   brake: engine exhaust brake

Wheel   & Types

Rims:   22.5×8.25,10 hole-steel

Tyres:   295/80R22.5  Tube 18 plies

with   one spare tyre

Driver’s   cab

MAN   technology L2000 long cab, all steel   forward control, 60^o hydraulically tiltable to the front,3-arm   windscreen wiper system with 3 speeds, laminate windscreen, with casted-in   radio aerial, hydraulically damped adjustable driver’s seat and rigid   adjustable co-driver’s seat, heating & ventilation system, single berth   with stereo radio/cassette recorder, sun visor, and adjustable steering   wheel.

With   alarm lamp on the top of cabin

Option:   air conditioner

Electrics

Operating   voltage:24V, negative grounded;    Starter: 24V, 5.4KW

Alternator:   28V, 1540W;  Batteries: 2x12, 165Ah

Cigar-lighter,   horn, headlamp, fog light, reverse lamp

Dimensions   in mm

Wheel   base

Front   wheel track

Rear   wheel track

Front   overhang

Rear   overhang

Approach   angle(^o)

Departure   angle(^o)

Overall   Dimension

Cargo   body size

5000

1995

1850

1320

2700

20.5

13

9000×2490×3000

-

Weight   in kg

Permissible   loading capacity

Dead   weight

Gross   vehicle weight

20000

8400

30000

Performance

Maximum   driving speed(km/h)

Maximum   grade ability (%)

Minimum   ground clearance(mm)

Minimum   turning circle(m)

Fuel   consumption(L/100km)

85   (With speed limiter 60km/h)

39

250

18.6

25
