Wheelbase

3200mm+1350mm

Front overhang

1320mm

Rear overhang

1600mm

Wheel track of front axle

2050mm

Wheel track of rear axle

1850mm

Chassis length

7470mm

Approach angle

21°

Departure angle

16°

Maximum driving speed

105 km/h

Maximum gradeability

35%

Minimum ground clearance

274mm

Minimum turning diameter

＜21m

Fuel consumption

30~32 L/100km

Cargo body size

6m³

Overall Dimension

7470mm×2496mm×2980mm

width of the cabin

H5B

Weight

Kerb.mass

12500kg

Gross vehicle weight

25500kg

Front axle loading capacity

5500kg

Rear axle loading capacity

10000kg×2

  Engine   Parameters

Engine Model

YC6J220-33

Rated Power

162/2500 (KW/rmp)

Maximum Torque

760/1400~1700 (Nm/rmp)

Features

6-cylinder in-line,6.494 liter

Clutch

395A diaphragm spring clutch, single plate

Gearbox

Gearbox Type

HW90510C 10 speed manual control

Gearbox ratio

1

11.987

2

8.976

3

6.748

4

4.644

5

3.805

6

2.581

7

1.932

8

1.453

9

1

10

0.819

R1

9.989

R2

2.151

Braking System

Type

Air brake system

Service brake

Dual-circuit air brake

Parking brake

Spring energy,

Compressed air operating on rear wheels

Auxiliary brake

Exhaust valve braking(EVB)

Wheels & Tyres

Tyres

11.00R20 10+1

Wheels

8.00V-20

Steering Gear

Type

D39
  Hydraulically assisted

Axles

Steer

153（5.5T）forging l-beam front axle

Drum brake

Drive

153（10.0T) Double bridge

Drum brake

153:i=5.143

Fuel Tank

Capacity

300 Liters (Aluminum)

Frame

Material

High tensile steel

Section

280*80*(8+8)mm

Frame width

865mm

Electrical System

Type

SINOTRUK CAN bus System with VCO instrument

Voltage

24V

Batteries

2x12V, 165Ah

Alternator

28V/80A

Starter

2.24KW

Suspension

Steer Axle

Semi-elliptical leaf springs with shock absorbers and stabilizer

Drive Axle

Bogie leaf springs with Integrated balance shaft and   stabilizer
