Wheelbase

3500mm

Front overhang

1260mm

Rear overhang

1800mm

Wheel track of front axle

1620mm

Wheel track of rear axle

1670mm

Chassis length

6360mm

Approach angle

33°

Departure angle

26°

Maximum driving speed

88 km/h

Maximum gradeability

28%~35%

Minimum ground clearance

380mm

Minimum turning diameter

＜16.5m

Fuel consumption

26~28(L/km)

Cargo body size

4200mm×2050mm×550mm

Overall Dimension

6560mm×2280mm×2710mm

width of the cabin

1880mm

Weight

Kerb.mass

4700kg

Gross vehicle weight

9500kg

Front axle loading capacity

2500kg

Rear axle loading capacity

7000kg

  Engine   Parameters

Engine Model

YC4102ZLQ

Rated Power

95/2800 (KW/rmp)

Maximum Torque

370/1800~2200 (Nm/rmp)

Features

4-cylinder in-line,3.922 liter

Clutch

325 diaphragm spring clutch, single plate

Gearbox

Gearbox Type

SC8T50C 8 speed manual control

Gearbox ratio

1

12.04

2

7.17

3

4.6

4

3.47

5

2.62

6

1.56

7

1

8

0.755

R1

11.31

R2

2.46

Braking System

Type

Air brake system

Service brake

Dual-circuit air brake

Parking brake

Spring energy,Compressed air operating on rear wheels

Auxiliary brake

Exhaust valve braking(EVB)

Wheels & Tyres

Tyres

8.25R20 6+1

Wheels

7.00T-20

Steering Gear

Type

GY90

Hydraulically assisted

Axles

Steer

2080（2.5T）forging l-beam front axle

Drum brake

Drive

1098D2（7.0T) central single reduction

Drum brake

1098D2:i=5.83

Fuel Tank

Capacity

120 Liters (iron )

Frame

Material

High tensile steel

Section

250*70*(6+5)mm

Frame width

800mm

Electrical System

Type

SINOTRUK CAN bus System with VCO instrument

Voltage

24V

Batteries

2x12V, 105Ah

Alternator

28V/50A

Starter

5KW

Suspension

Steer Axle

Semi-elliptical leaf springs with shock absorbers and stabilizer

Drive Axle

springs Suspension
