Dimension

2270   x1300x1080 (LxWxH mm)

1641x1300x1084 (LxWxH mm)

610 x1120   x1310 (LxWxH mm)

Weight

272Kg/600lb

182Kg/401lb

80Kg/176lb

Hopper   capacity

70.6 cu ft/4850   lb (2cu m/2200 kg)

35.3 cu ft/2645lb (1cu m/1200 kg)

10.6 cu ft/805 lb (0.3 cu m/365 kg)

Spread   agent

Salt, sand, pebbles, snow melt

Hopper   construction

Polyethylene

Material   Deflector

Adjustable poly   deflector（Φ16CM *23CM）

Adjustable poly   deflector（Φ16CM *23CM）

Adjustable poly deflector

Deflector   capacity

0.06m3/min

Gear   ratio

1:80

1:80

Motor

DC12V（24V Optional ）600 w

DC12V（24V Optional ）600 w

DC12V（24V Optional ）250 w

Vibrating   motor

Dual vibrating   DC12V（24V Optional ）

 0.2kN DC12V（24V Optional ）

Spinner

36.8cm   Diameter Poly Spinner

36.8cm   Diameter Poly Spinner

31cm Diameter Poly Spinner

Spread   width

0-12   m

Receiver   Hitch

     Class 4

Spinner   designer

easy   disassembly

Control

Dual variable   speed control with explosion-proof function and overload protection

Minimum   Box length

168CM

Vehicle   Applications

3/4；1-4   tons light truck

3/4；1-4 tons light truck and Pick- up

3/4；1-4 tons light truck
